PiezoJet Printer(P5Pro)

Intelligent control, flexible installation

LEAD TECH P Series high resolution inkjet printer alows to connect P3, P5 P7 printhead individuall.

One button flush, low ink alarm, constant temperature heat system ensures printer stability and reliability.

inquiry 》

Proofing 》

Performance Parameter

Application

Data download

Model

P5Pro

Printhead Type

RICOH(MH5420)

Operation System

Android operation system

Print Speed

Max. 260 m/min

Print Distance

3-5mm

Print Resolution

Vertical: 150/300/600 DPI

Horizontal: 150/300/600 DPI

Ink System

Siphon Ink Supply

Print Height

54mm

I/O Ports

4 Ports for printhead, Alarm Light, Encode and Sensor, USB port and Ethernet port

Printer Screen

10.2 inch industrial touch screen

Power

110-240V , DC24V 5A

System Language

English, Chinese, Russian, Spanish, Portuguese, Arabic, Korean, Japanese and other languages can be upgraded

Print Message

Text, Variable Text, Date, Time, Shift, Counter, Database Text, Bar code, Graphics, Table and QR Codes

Support Database Type

TXT、Excel、Access、SQL Server

Installation

Sideward and Downward Printing with standard bracket Optional Precise Adjustable bracket

Ink Type

Oil based and UV Ink

Ink Manage

Auto-identify Ink Type and Confirm Optional Parameters; Auto-calculate Ink Consumption

Working Temperature

59°F(15°C)-104°F(40°C)

Storage Temperature

41°F(5°C)-113°F(45°C)

Printhead specifications

355mmx135mmx58mm

Net Weight

1.2Kg

Food industry, medicine and health care, beverage and beverage, daily chemical industry, auto parts industry, pipe industry, CCB industry, living paper, chemical industry, tobacco industry
